| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | EDAC |
| Manufacturer Part Number: | EDAC 337-040-560-808 |
| Color: | Green |
| Amperage: | 3 A |
| Gender: | Female |
| Number of Contacts: | 40 |
| Number of Rows: | 2 |
| Contact Material: | Copper Alloy |
| Contact Plating: | Gold, Nickel, Tin |
| Pitch: | 0.156 in |
| Insulation Material: | Thermoplastic Polyester |
| Row Spacing: | .2 in |
| Number of Positions: | 40 |
| Mount Orientation: | Straight |
| Operating Temperature Range: | -40 - 105 °C |
| Current Rating: | 3 A |
| Voltage Rating: | 1800 VAC |
| Card Thickness: | 0.062 in |
| Operating Temperature: | -40 to 105 °C |
| Mounting Type: | Screw Mount |
| SKU: | EDA337-040-560-808 |
337-040-560-808
| ICC Number: | EDA337-040-560-808 |
| Manufacturer: | EDAC |
| Manufacturer Number: | 337-040-560-808 |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the 337-040-560-808 Card Edge Connector, a high-performance solution for your PCB connectivity needs. With its durable UL 94V-0 Thermoplastic Polyester housing and copper alloy contact material, this connector ensures reliable power and signal transmission. Featuring two rows of 40 positions and a pitch of .156 inches, it offers ample connectivity options for your applications. The green color coding and straight mount orientation make for easy identification and installation. Operating flawlessly in temperatures ranging from -40 to 105°C, this connector is suitable for a wide range of environments. Trust in the 337-040-560-808 for secure and efficient board-to-board connections in your projects.
