163X10169X

D-SUB High Density, 15-pos., Plug, Crimp, Through hole

Attribute	Value
Product Category:	D-Sub & D-Ribbon Connectors & Accessories D-Sub Connectors
Manufacturer:	CONEC
Manufacturer Part Number:	CONEC 163X10169X
Gender:	Male
Housing Material:	Steel
Number of Contacts:	15
Termination Method:	Crimp
Contact Material:	Copper Alloy
Contact Plating:	Gold Over Nickel
Insulation Material:	Nylon
Wire Size:	28 to 22 AWG
Current Rating:	3 A
Voltage Rating:	60 V
Operating Temperature:	-55 to 125 °C
Mounting Type:	Through Hole
D-Sub Connector Type:	High Density
SKU:	COC163X10169X
