| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Cinch Connectivity Solutions |
| Manufacturer Part Number: | Cinch Connectivity Solutions MS24264R14B7P8 |
| Military Specification: | MIL-C-26500 |
| Series: | Omega |
| Gender: | Male |
| Housing Material: | Aluminum |
| Number of Contacts: | 7 |
| Mount Type: | Panel Mount |
| Termination Method: | Crimp |
| Maximum Operating Temperature: | 200 °C |
| Minimum Operating Temperature: | -55 °C |
| Shell Size: | 14 |
| Contact Type: | Pin |
| Mating Type: | Bayonet |
| Seal Material: | Fluorosilicone, Silicone Rubber |
| Shell Size - Insert Arrangement: | 14-7 |
| Shell Material: | Aluminum |
| Mating Cycles: | 500 cycle |
| Shell Type: | Square Flange Receptacle |
| Shell Finish: | Anodized |
| Current Rating: | 13 A |
| Voltage Rating: | 1500 VAC |
| Insert Arrangement: | 14-7 |
| Locking Mechanism: | Bayonet |
| SKU: | CIMMS24264R14B7P8 |
MS24264R14B7P8
| Heilind Number: | CIMMS24264R14B7P8 |
| Manufacturer: | Cinch Connectivity Solutions |
| Manufacturer Number: | MS24264R14B7P8 |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the MS24264R14B7P8, a rugged and reliable male circular connector from the Omega series that meets MIL-DTL-26500 military specifications. With a durable aluminum housing and panel mount design, this connector is built to withstand harsh environments. Featuring 7 crimp termination contacts, it ensures secure and efficient connections in high vibration settings. The silicone rubber and fluorosilicone seals provide excellent protection, allowing for a wide operating temperature range from -55°C to 200°C. With a shell size of 14 and bayonet mating type, this connector offers easy and secure installation. Rated for 13A and 1500VAC, it is suitable for high-power applications. Designed for 500 mating cycles, the MS24264R14B7P8 guarantees long-term performance in demanding conditions. Not RoHS compliant.
