| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol FCI Berg |
| Manufacturer Part Number: | Amphenol FCI Berg 68001-104HLF |
| Color: | Black |
| Series: | BergStik® |
| Housing Material: | Glass-Filled Nylon/Liquid Crystal Polymer |
| Number of Contacts: | 4 |
| Number of Rows: | 1 |
| Mount Type: | Through Hole |
| Contact Material: | Phosphor Bronze |
| Contact Plating: | Gold/GXT Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -65 °C |
| Pitch: | 2.54 mm |
| Mount Angle: | Straight |
| Tail Length: | 3.05 mm |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 3 A |
| Voltage Rating: | 1500 VAC |
| Mating Length: | 5.84 mm |
| SKU: | BRG68001-104HLF |
68001-104HLF
| Heilind Number: | BRG68001-104HLF |
| Manufacturer: | Amphenol FCI Berg |
| Manufacturer Number: | 68001-104HLF |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the B/S II HDR ( 68001-104HLF), a high-performance black BergStik® connector designed for reliable through-hole mounting on PCBs. Constructed with a durable housing made of glass-filled nylon and liquid crystal polymer, this connector features four gold-plated phosphor bronze contacts, offering excellent conductivity and signal integrity. With a wide operating temperature range from -65°C to 125°C and a voltage rating of 1500 VAC, it ensures dependable performance in demanding environments. Its straight mount angle and 2.54 mm pitch make it ideal for space-constrained applications, while its UL 94V-0 flammability rating guarantees safety. In stock and RoHS compliant, the B/S II HDR is the perfect choice for your high-reliability connector needs.
Frequently Bought Together
| Product | Part # | Description | Stock |
|---|---|---|---|
 | Amphenol FCI Berg 67997-206HLF | B/S II DR |  |
 | Amphenol FCI Berg 68001-102HLF | B/S HEADER SR | |
 | Amphenol FCI Berg DILB40P-223TLF | DILB ASSEMBLY | |
Product Change Notice
| Effective Date | Description of Change | Download | |||
|---|---|---|---|---|---|
| 02/01/2016 | PCN15138 - Location Change. To support selected Bergstik header parts in FCI Nantong in China, FCI proposes to add FCI Besancon in France also as a manufacturing site. | Download | |||
