65039-032LF
MINI LATCH HSG SR.100
The 65039-032LF, a high-quality MINI LATCH HSG SR.100 female connector housing designed for reliable and durable performance in various applications. Constructed from a robust blend of Polyphenylene and Polystyrene, this housing ensures excellent longevity even in demanding environments. With 5 contacts arranged in a single row and a convenient crimp termination method, it offers easy and efficient connectivity. Operating flawlessly between -40°C and 105°C, it guarantees reliable performance in both extreme cold and hot conditions. Featuring a 2.54mm pitch, Latch mating type, and straight mount angle, it facilitates seamless integration into your systems. With low contact resistance of 2 mΩ, high insulation resistance of 100000 MOhm, and a voltage rating of 1000V, this connector housing guarantees superior signal integrity and safety. Its UL 94V-0 flammability rating and RoHS compliance further ensure the highest standards of quality and environmental responsibility. Perfect for use in various hi-rel applications, the 65039-032LF is the ideal choice for your connectivity needs.
| Product Category: | |
| Manufacturer: | Amphenol FCI Berg |
| Manufacturer Part Number: | 65039-032LF |
| Gender: | Female |
| Housing Material: | Polyphenylene, Polystyrene |
| Number of Contacts: | 5 |
| Number of Rows: | 1 |
| Termination Method: | Crimp |
| Maximum Operating Temperature: | 105 °C |
| Minimum Operating Temperature: | -40 °C |
| Pitch: | 2.54 mm |
| Mating Type: | Latch |
| Mount Angle: | Straight |
| Contact Resistance: | 2 mΩ |
| Housing Color: | Black |
| Insulation Resistance: | 100000 MOhm |
| Mating Cycles: | 1000 cycle |
| Wire Size: | 36 - 22 AWG |
| Flammability Rating: | UL 94V-0 |
| Voltage Rating: | 1000 V |
| SKU: | BRG65039-032LF |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
