| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol FCI Berg |
| Manufacturer Part Number: | Amphenol FCI Berg 61082-101402LF |
| Gender: | Female |
| Housing Material: | Glass-Filled Liquid Crystal Polymer |
| Number of Contacts: | 10 |
| Number of Rows: | 2 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Gold |
| Pitch: | 0.8 mm |
| Current Rating: | 0.8 A |
| Voltage Rating: | 100 VAC |
| Mated Stacking Height: | 5 mm, 6 mm, 7 mm, 8 mm |
| Operating Temperature: | -40 to 125 °C |
| Mounting Angle: | Straight |
| Mounting Type: | PCB Mount |
| SKU: | BRG61082-101402LF |
61082-101402LF
| ICC Number: | BRG61082-101402LF |
| Manufacturer: | Amphenol FCI Berg |
| Manufacturer Number: | 61082-101402LF |
| Datasheet: | Datasheet |
| ECAD Model: |
Description:
0.8MM B TO B REC ASSY
Specifications
Frequently Bought Together
| Product | Part # | Description | Stock |
|---|---|---|---|
 | Amphenol FCI Berg 10144518-061802LF | OEM ITEM 10144518-061802LF-0.8MM P1 60P |  |
Product Change Notice
| Effective Date | Description of Change | Download | |||
|---|---|---|---|---|---|
| 07/30/2026 | PCN26125 - Process Change. Introduction of new Dies for Bergstak 0.8mm Old Dies were worn out and have to replace with new dies to continue production. | Download | |||
| 03/30/2018 | PCN17100 - Packaging Change. To unify the carrier tapes' pitch of selected Bergstak receptacle and plug, from 16mm pitch to 12mm pitch. Refer to attached documentation for easy understanding.Reel packing qty keeps same as before, without any change for SPQ or MOQ. | Download | |||
| 02/28/2015 | PCN14080 - Materials Change. | Download | |||
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
