901-9531-2SF
RF Connector SMA Right Angle Crimp Plug RG-58 RG-141 Times LMR-195 50 Ohm
The 901-9531-2SF, a high-performance RF Connector designed for seamless connectivity in demanding applications. This SMA Right Angle Crimp Plug is compatible with RG-58, RG-141, Times LMR-195, and other cables, boasting a low 50 Ohm impedance for efficient signal transmission. Constructed with durable stainless steel and beryllium copper contacts, this connector ensures reliable performance even in harsh environments, with a wide operating temperature range from -65°C to 165°C. Its threaded coupling mechanism guarantees secure mating, while its RoHS compliance underscores its commitment to environmental responsibility. Ideal for use in telecommunications, aerospace, and military applications, the 901-9531-2SF is a trusted solution for high-reliability RF connections.
| Product Category: | |
| Manufacturer: | Amphenol RF |
| Manufacturer Part Number: | Amphenol RF 901-9531-2SF |
| Connector Type: | SMA |
| Gender: | Plug |
| Termination Method: | Cable - Crimp |
| Contact Material: | Beryllium Copper |
| Maximum Operating Temperature: | 165 °C |
| Minimum Operating Temperature: | -65 °C |
| IP Rating: | Not Rated |
| Orientation: | Right Angle |
| Impedance: | 50 Ω |
| Operating Frequency: | 12.4 Max GHz |
| Body Material: | Stainless Steel |
| Panel Mount Type: | Not Applicable |
| Body Finish: | Passivated |
| Coupling Type: | Threaded |
| SKU: | AMR901-9531-2SF |
| Mil Qualified: | No |
| Cable Group: | C |
| Cable Type: | RG-58,RG-141,Times LMR-195,Times LMR-200-LLPL,Belden 7806A,Belden 8219,Belden 8240,Belden 8259,Belden 8262,Belden 9201,Belden 9203,Belden 9310,Belden 9311 |
| Insulator Material: | PTFE |
| Operating Level: | Commercial |
| Isolated: | No |
| Low PIM: | No |
| Non Magnetic: | No |
| Thread Direction: | Standard |
| Contact Finish: | Gold |
| Contact Termination: | Solder |
| Mating Cycles (Min): | 100 |
| Assembly Tool: | CTL-3 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
