222114-10
RF Connector F-Type Straight Crimp Jack RG-179 Belden 179DT Bulkhead Rear Mount 75 Ohm
The 222114-10, a high-performance RF Connector designed for seamless connectivity in electronic systems. This F-Type Straight Crimp Jack is meticulously crafted for precision, boasting a durable body made of nickel-finished brass. With a panel mount feature for Bulkhead Rear Mount installation, it ensures secure placement for optimal signal transmission. Operating at temperatures ranging from -55°C to 85°C, this connector is reliable in various environments. Its 75 Ohm impedance and 2 GHz operating frequency make it ideal for high-speed applications. RoHS compliant and featuring beryllium copper contacts, the 222114-10 guarantees both performance and safety in every use case. Upgrade your connectivity with this top-of-the-line RF Connector.
| Product Category: | |
| Manufacturer: | Amphenol RF |
| Manufacturer Part Number: | Amphenol RF 222114-10 |
| Connector Type: | F-Type |
| Gender: | Jack |
| Termination Method: | Cable - Crimp |
| Contact Material: | Beryllium Copper |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | Not Rated |
| Orientation: | Straight |
| Impedance: | 75 Ω |
| Operating Frequency: | 2 Max GHz |
| Body Material: | Brass |
| Panel Mount Type: | Bulkhead - Rear Mount |
| Body Finish: | Nickel |
| Coupling Type: | Threaded |
| SKU: | AMR222114-10 |
| Mil Qualified: | No |
| Cable Group: | S |
| Cable Type: | RG-161,RG-179,RG-187,Belden 179DT,Belden 1520A,Belden 1521A,Belden 1522A,Belden 9221 |
| Insulator Material: | Polypropylene |
| Operating Level: | Commercial |
| Isolated: | No |
| Low PIM: | No |
| Non Magnetic: | No |
| Thread Direction: | Standard |
| Contact Finish: | Gold |
| Contact Termination: | Solder |
| Mating Cycles (Min): | 500 |
| Assembly Tool: | 47-10150 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
