| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol RF |
| Manufacturer Part Number: | Amphenol RF 172176 |
| Connector Type: | N-Type |
| Gender: | Plug |
| Termination Method: | Cable - Crimp |
| Contact Material: | Beryllium Copper |
| Maximum Operating Temperature: | 165 °C |
| Minimum Operating Temperature: | -65 °C |
| IP Rating: | Not Rated |
| Orientation: | Right Angle |
| Impedance: | 50 Ω |
| Operating Frequency: | 11 Max GHz |
| Body Material: | Brass |
| Panel Mount Type: | Not Applicable |
| Body Finish: | White Bronze |
| Coupling Type: | Threaded |
| SKU: | AMR172176 |
| Mil Qualified: | No |
| Cable Group: | E |
| Cable Type: | RG-8,RG-213,RG-225,Times AA-4478,Belden 8267,Belden 9251,Belden 9880,Belden 89880,Belden 8242,Belden 8268 |
| Insulator Material: | PTFE |
| Isolated: | No |
| Low PIM: | No |
| Non Magnetic: | No |
| Thread Direction: | Standard |
| Contact Finish: | Gold |
| Contact Termination: | Solder |
| Mating Cycles (Min): | 500 |
| Assembly Tool: | 47-10210 |
172176
| Heilind Number: | AMR172176 |
| Manufacturer: | Amphenol RF |
| Manufacturer Number: | 172176 |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the 172176, a high-performance RF Connector designed for seamless connectivity in demanding applications. This N-Type Right Angle Crimp Plug is engineered for precision, compatible with RG-8, RG-213, and RG-225 cables, ensuring a secure and reliable connection. With a low impedance of 50 Ohms and a maximum operating frequency of 11 GHz, this connector is ideal for high-speed data transmission. Constructed with durable beryllium copper contacts and a brass body with a white bronze finish, it guarantees longevity even in harsh environments. RoHS compliant and featuring a convenient threaded coupling, the 172176 is the perfect choice for professionals seeking top-tier RF connectivity solutions.
