| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol RF |
| Manufacturer Part Number: | Amphenol RF 172100 |
| Connector Type: | N-Type |
| Gender: | Plug |
| Termination Method: | Cable - Crimp |
| Contact Material: | Brass |
| Maximum Operating Temperature: | 165 °C |
| Minimum Operating Temperature: | -65 °C |
| IP Rating: | Not Rated |
| Orientation: | Straight |
| Impedance: | 50 Ω |
| Operating Frequency: | 11 Max GHz |
| Body Material: | Brass |
| Panel Mount Type: | Not Applicable |
| Body Finish: | White Bronze |
| Coupling Type: | Threaded |
| SKU: | AMR172100 |
172100
| Heilind Number: | AMR172100 |
| Manufacturer: | Amphenol RF |
| Manufacturer Number: | 172100 |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the 172100, a high-performance RF Connector designed for seamless connectivity in a variety of applications. This N-Type Straight Crimp Plug is compatible with RG-58, RG-141, Times LMR-195, and offers a reliable 50 Ohm impedance. Constructed with durable Brass and featuring a White Bronze finish, this connector ensures optimal signal transmission even in harsh environments. With a straight orientation and threaded coupling type, it guarantees a secure and stable connection. RoHS compliant and operating efficiently between -65 °C and 165 °C, the 172100 is a versatile and dependable solution for your RF coaxial connectivity needs. Available for immediate shipping.
