132195
RF Connector SMA Straight Crimp Plug RG-55 RG-142 RG-223 RG-400 50 Ohm
The 132195, a high-performance RF Connector designed for seamless connectivity in demanding applications. This SMA Straight Crimp Plug boasts compatibility with RG-55, RG-142, RG-223, and RG-400 cables, offering versatility for various setups. With a low impedance of 50 Ohms, it ensures efficient signal transmission with minimal loss. Constructed with durable brass and featuring a gold body finish, this connector guarantees reliable performance even in harsh environments. Its threaded coupling type enhances stability, while the straight orientation allows for easy installation in tight spaces. RoHS compliant and rated for operating temperatures between -65°C and 165°C, the 132195 is a dependable choice for professional RF systems.
| Product Category: | |
| Manufacturer: | Amphenol RF |
| Manufacturer Part Number: | Amphenol RF 132195 |
| Connector Type: | SMA |
| Gender: | Plug |
| Termination Method: | Cable - Crimp |
| Contact Material: | Brass |
| Maximum Operating Temperature: | 165 °C |
| Minimum Operating Temperature: | -65 °C |
| IP Rating: | Not Rated |
| Orientation: | Straight |
| Impedance: | 50 Ω |
| Operating Frequency: | 12.4 Max GHz |
| Body Material: | Brass |
| Panel Mount Type: | Not Applicable |
| Body Finish: | Gold |
| Coupling Type: | Threaded |
| SKU: | AMR132195 |
| Mil Qualified: | No |
| Cable Group: | C1 |
| Cable Type: | RG-55,RG-142,RG-223,RG-400,Belden 83242,Times SF-142B |
| Insulator Material: | PTFE |
| Isolated: | No |
| Low PIM: | No |
| Non Magnetic: | No |
| Thread Direction: | Standard |
| Contact Finish: | Gold |
| Contact Termination: | Solder |
| Mating Cycles (Min): | 500 |
| Assembly Tool: | 47-10070 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
Product Change Notice
| Effective Date | Description of Change | Download |
|---|---|---|
| 10/30/2024 | AMR-103024 - COO Change. Manufacturing Location / Country of Origin: From China (CN) to Vietnam (VN) | Download |
