082-97-RFX
RF Connector N-Type Panel Mount Jack 4-Hole Flange Solder Cup 50 Ohm
The 082-97-RFX, a high-performance RF Connector designed for seamless connectivity in demanding applications. This N-Type Panel Mount Jack features a robust 4-Hole Flange for secure installation, along with a convenient Solder Cup termination method. Constructed from durable Brass with a Nickel finish, it ensures reliable signal transmission even in harsh environments. The Beryllium Copper contact material guarantees excellent conductivity, while the 50 Ohm impedance is ideal for high-frequency signals up to 11 GHz. With a wide operating temperature range from -65°C to 165°C, this connector is suited for both indoor and outdoor use. RoHS compliant and in stock for immediate shipping, it's the perfect choice for your RF coaxial connectivity needs.
Details
| Product Category: | |
| Manufacturer: | Amphenol RF |
| Manufacturer Part Number: | Amphenol RF 082-97-RFX |
| Connector Type: | N-Type |
| Gender: | Jack |
| Termination Method: | Solder Cup |
| Contact Material: | Beryllium Copper |
| Maximum Operating Temperature: | 165 °C |
| Minimum Operating Temperature: | -65 °C |
| IP Rating: | Not Rated |
| Orientation: | Straight |
| Impedance: | 50 Ω |
| Operating Frequency: | 11 Max GHz |
| Body Material: | Brass |
| Panel Mount Type: | 4-Hole Flange |
| Body Finish: | Nickel |
| Coupling Type: | Threaded |
| SKU: | AMR082-97-RFX |
| Mil Qualified: | No |
| Cable Group: | Not Applicable |
| Cable Type: | Not Applicable |
| Insulator Material: | PTFE |
| Isolated: | No |
| Low PIM: | No |
| Non Magnetic: | No |
| Thread Direction: | Standard |
| Contact Finish: | Gold |
| Contact Termination: | Solder |
| Mating Cycles (Min): | 500 |
Frequently bought together
Compliance
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
