031-321
RF Connector BNC Straight Crimp Plug RG-59 RG-62 50 Ohm
The 031-321, a high-performance RF Connector designed for seamless connectivity in professional audio and video applications. This BNC Straight Crimp Plug boasts compatibility with RG-59 and RG-62 cables, featuring a 50 Ohm impedance for reliable signal transmission. Constructed with durable brass and nickel finishing, it ensures longevity even in harsh environments, with a wide operating temperature range from -65°C to 165°C. The Bayonet coupling type offers easy and secure connections, while its RoHS compliance guarantees environmental responsibility. Ideal for high-frequency applications up to 4 GHz, this connector is a must-have for broadcast, telecommunications, and military industries. Upgrade your connectivity with the 031-321 and experience uncompromising performance.
| Product Category: | |
| Manufacturer: | Amphenol RF |
| Manufacturer Part Number: | Amphenol RF 031-321 |
| Connector Type: | BNC |
| Gender: | Plug |
| Termination Method: | Cable - Crimp |
| Contact Material: | Brass |
| Maximum Operating Temperature: | 165 °C |
| Minimum Operating Temperature: | -65 °C |
| IP Rating: | Not Rated |
| Orientation: | Straight |
| Impedance: | 50 Ω |
| Operating Frequency: | 4 Max GHz |
| Body Material: | Brass |
| Panel Mount Type: | Not Applicable |
| Body Finish: | Nickel |
| Coupling Type: | Bayonet |
| SKU: | AMR031-321 |
| Mil Qualified: | No |
| Cable Group: | D |
| Cable Type: | RG-59,RG-62,Belden 8221,Belden 8241,Belden 9169,Belden 9204,Belden 9228,Canare LV-61S |
| Insulator Material: | PTFE |
| Isolated: | No |
| Low PIM: | No |
| Non Magnetic: | No |
| Contact Finish: | Gold |
| Contact Termination: | Crimp |
| Mating Cycles (Min): | 500 |
| Assembly Tool: | CTL-8 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
