928958-7

AMP928958-7
Heilind Number:AMP928958-7
Manufacturer:TE Connectivity
Manufacturer Number:928958-7
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

PL 250 REC TERMINAL 13-11 AWG PTPPB

More >>

Specifications

AttributeValue
Product Category:
Crimp Terminals, Housings, Splices, & Lugs Crimp Terminals, Housings, & Splices
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 928958-7
Series:Positive Lock 250
Contact Material:Phosphor Bronze
Contact Plating:Pre-Tin
Overall Length:22.3 mm, .88 in
Material:Phosphor Bronze
Compatible Tab Width:.25 in, 6.35 mm
Compatible Tab Thickness:.032 in, .81 mm
Terminal Type:Receptacle
Orientation:Straight
Operating Temperature Range:-40 - 110 °C, -40 - 230 °F
Wire Size:13 - 11 AWG, 2.62 - 4.17 mm²
Crimp Type:F-Crimp
Barrel Type:Open
Accepts Wire Insulation Diameter:.13 - .185 in, 3.3 - 4.7 mm
Product:Quick Disconnects
Product Type:Receptacle
SKU:AMP928958-7

Detailed Description

The 928958-7 is a high-quality PL 250 REC TERMINAL designed for secure and efficient wire connections. Constructed from durable Phosphor Bronze with a Pre-Tin contact plating, this straight receptacle ensures reliable performance even in harsh environments, with an operating temperature range of -40 to 110°C (-40 to 230°F). Suitable for 13-11 AWG wires (2.62-4.17 mm²), it features a F-Crimp for easy installation and an open barrel for enhanced conductivity. RoHS compliant and part of the Positive Lock 250 series, this terminal guarantees both safety and performance in a variety of applications.
