927892-1

Heilind Number:	AMP927892-1
Manufacturer:	TE Connectivity
Manufacturer Number:	927892-1
Datasheet:	Application Specification
ECAD Model:

Description:

FF 110 TAB 0.5-1 MM2 PTP CUSN30

More >>

Specifications

Attribute	Value
Product Category:	Crimp Terminals, Housings, Splices, & Lugs Crimp Terminals, Housings, & Splices
Manufacturer:	TE Connectivity
Manufacturer Part Number:	TE Connectivity 927892-1
Series:	FASTIN-FASTON 110
Contact Material:	CuZn30
Contact Plating:	Tin
Overall Length:	22.5 mm, .886 in
Compatible Tab Width:	.11 in, 2.8 mm
Compatible Tab Thickness:	.031 in, .79 mm
Terminal Type:	Tab
Orientation:	Straight
Operating Temperature Range:	-40 - 130 °C, -40 - 266 °F
Wire Size:	1021 - 2048 CMA, 17 - 20 AWG
Crimp Type:	F-Crimp
Barrel Type:	Open
Accepts Wire Insulation Diameter:	.063 - .087 in, 1.6 - 2.2 mm
Product:	Quick Disconnects
SKU:	AMP927892-1
Fully Insulated:	No
Connection Capacity:	Single
Wire Size:	.5 - 1 mm²
Mating Retention Type:	Locking Lance
Locking Lance Height:	1.2 mm / .047 in
Quick Disconnect Packaging Method:	Reel
Wire/Cable Type:	Regular Wire
Sealable:	No
Insulated:	No
Terminates To:	Wire & Cable
Part Alias:	C75578-000,AMPS-0-0927892-1

Detailed Description

Introducing the 927892-1, a high-quality Fastin-Faston 110 tab terminal designed for efficient electrical connections. Constructed with CuZn30 contact material and tin plating, this terminal ensures reliable conductivity. With an overall length of .886 inches and a compatible tab width of .11 inches, it is suitable for a variety of applications. The straight orientation and F-Crimp type make for easy installation, accommodating wire sizes ranging from 17 to 20 AWG. Operating in temperatures from -40 to 130°C, this terminal is ideal for HVAC systems and other industrial settings. RoHS compliant and part of the Quick Disconnects product line, the 927892-1 guarantees both performance and environmental responsibility. Upgrade your connectivity solutions with this durable and versatile terminal.
