880683-3

AMP880683-3
Heilind Number:AMP880683-3
Manufacturer:TE Connectivity
Manufacturer Number:880683-3
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

.250 SERIES FASTON

More >>

Specifications

AttributeValue
Product Category:
Crimp Terminals, Housings, Splices, & Lugs Crimp Terminals, Housings, & Splices
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 880683-3
Series:FASTON 250
Contact Material:Phosphor Bronze
Contact Plating:Unplated
Overall Length:16.3 mm, .642 in
Material:Phosphor Bronze
Compatible Tab Width:.25 in, 6.35 mm
Compatible Tab Thickness:.032 in, .81 mm
Terminal Type:Receptacle
Orientation:Straight
Wire Size:17 - 20 AWG, .51 - 1.03 mm²
Crimp Type:F-Crimp
Barrel Type:Open
Accepts Wire Insulation Diameter:.079 - .13 in, 2.01 - 3.3 mm
Product:Quick Disconnects
Product Type:Receptacle
SKU:AMP880683-3

Detailed Description

Introducing the 880683-3, a high-quality FASTON 250 series straight receptacle terminal designed for efficient wire connections. Constructed with unplated phosphor bronze contact material, this terminal ensures reliable conductivity. With an overall length of 16.3mm (.642 in) and compatible with 6.35mm (.25 in) tab widths, it accommodates 17-20 AWG (.51-1.03 mm²) wire sizes. The F-Crimp design and open barrel make for easy and secure installations. Notably, the terminal is not RoHS compliant. Trust in the 880683-3 for your quick disconnect applications, a dependable solution for various projects.
