63703-1

AMP63703-1
Heilind Number:AMP63703-1
Manufacturer:TE Connectivity
Manufacturer Number:63703-1
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

FASTON .110 RECEPTACLE 20-16 AWG PTPBR

More >>

Specifications

AttributeValue
Product Category:
Crimp Terminals, Housings, Splices, & Lugs Crimp Terminals, Housings, & Splices
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 63703-1
Series:FASTON 110
Contact Material:Brass
Contact Plating:Tin
Overall Length:16.13 mm, .635 in
Material:Brass
Compatible Tab Width:.11 in, 2.8 mm
Compatible Tab Thickness:.032 in, .81 mm
Terminal Type:Receptacle
Orientation:Straight
Operating Temperature Range:-40 - 110 °C, -40 - 230 °F
Wire Size:16 - 20 AWG, .51 - 1.31 mm²
Crimp Type:F-Crimp
Barrel Type:Open
Accepts Wire Insulation Diameter:.12 - .14 in, 3.05 - 3.56 mm
Product:Quick Disconnects
Product Type:Receptacle
SKU:AMP63703-1
Fully Insulated:No
Connection Capacity:Single
Receptacle Terminal Stock Thickness:.25 mm / .01 in
UL Rating:Listed
CSA Certified:Yes
Mating Retention Type:Dimple
Wire Insulation Support:With
Wire/Cable Type:Regular Wire
Sealable:No
Insulated:No
Wire Stop:No
Terminates To:Wire & Cable

Detailed Description

Introducing the 63703-1, a reliable and efficient FASTON .110 Receptacle designed for 20-16 AWG wire connections. Constructed with durable brass and featuring tin plating, this terminal ensures excellent conductivity and corrosion resistance. With an overall length of .635 inches, it accommodates standard tab widths of .11 inches and thicknesses of .032 inches. The straight orientation and F-Crimp design make for easy and secure installations. Operating flawlessly in temperatures ranging from -40 to 110°C, this receptacle is perfect for various applications, including HVAC systems. RoHS compliant and part of the Quick Disconnects product line, it guarantees quality and performance. Upgrade your terminals to the 63703-1 for seamless connectivity in your projects.
