61627-2

AMP61627-2
Heilind Number:AMP61627-2
Manufacturer:TE Connectivity
Manufacturer Number:61627-2
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

.140 DIA PIN 20-14 PTPPHBZ

More >>

Specifications

AttributeValue
Product Category:
Power Connectors Battery & Coin Cell Clips, Contacts & Holders
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 61627-2
Series:Commercial MATE-N-LOK
Accessory Type:Contact
Mount Type:Cable Mount (Free-Hanging)
Termination Method:Crimp
Contact Material:Phosphor Bronze
Voltage:250 VAC
Contact Type:Pin
Package Quantity:2500
Cable Type:Discrete Wire
Contact Amperage:17 A
Termination Type:Crimp
GPL:237
Packaging:Reel
Operating Temperature Range:-55 - 105 °C, -67 - 221 °F
Circuit Application:Power
Contact Mating Area Plating:Tin
GPL Description:Appliances
Connector and Contact Terminate To:Wire & Cable
Product Code:1363
Wire Size:14 - 20 AWG, .5 - 2 mm²
Connector System:Wire to Wire
UL Agency Certification:E28476
Contact Termination Plating:Tin
ECCN:EAR99
Wire Insulation Support:With
Accepts Wire Insulation Diameter:.1 - .18 in, 2.54 - 4.57 mm
Contact Retention:With
Glow Wire Rating:Standard Part - Not Glow Wire
For Multiple Crimp:No
Contact Orientation:Straight
Wire Contact Termination Area Plating Material:Tin
Contact Retention Type in Housing:Locking Lance
Contact Product Type:Contact
Mating Pin Diameter:.14 in, 3.56 mm
Standards Met:UL UL 94V-2
Material Flammability Standard:UL 94V-2
Part Aliases:61627-2
SKU:AMP61627-2

Detailed Description

Introducing the 61627-2 Commercial MATE-N-LOK Contact, a reliable solution for power applications. This cable mount contact, with a termination method of crimping, is constructed of durable phosphor bronze with tin plating for enhanced conductivity. UL and UL 94V-2 standards ensure safety and performance. Suitable for 14-20 AWG wires, this contact accommodates a voltage of 250 VAC and an amperage of 17 A, making it ideal for various power systems. Its straight orientation and locking lance retention offer secure connections, while its RoHS compliance underlines its environmental responsibility. With a package quantity of 2500 on a reel, the 61627-2 is perfect for high-volume assembly in appliances and other applications.
