60900-4

AMP60900-4
Heilind Number:AMP60900-4
Manufacturer:TE Connectivity
Manufacturer Number:60900-4
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

WRAP TYPE TAB REC 24-22 AWG TPBR

More >>

Specifications

AttributeValue
Product Category:
Crimp Terminals, Housings, Splices, & Lugs Crimp Terminals, Housings, & Splices
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 60900-4
Series:Special Purpose Terminals
Contact Material:Brass
Contact Plating:Tin
Overall Length:11.73 mm, .462 in
Material:Brass
Compatible Tab Width:.062 in, 1.57 mm
Compatible Tab Thickness:.032 in, .81 mm
Terminal Type:Receptacle
Orientation:Straight
Operating Temperature Range:-40 - 110 °C, -40 - 230 °F
Wire Size:20 - 24 AWG, .2 - .51 mm²
Crimp Type:F-Crimp
Barrel Type:Open
Accepts Wire Insulation Diameter:.04 - .08 in, 1.02 - 2.03 mm
Product:Quick Disconnects
Product Type:Receptacle
SKU:AMP60900-4

Detailed Description

Introducing the 60900-4, a high-quality WRAP TYPE TAB REC designed for 24-22 AWG wire connections. Constructed with durable brass and featuring tin plating, this receptacle ensures reliable conductivity. With an overall length of .462 inches and a straight orientation, it offers easy installation in various applications. Suitable for wire sizes 20-24 AWG, it accommodates insulation diameters ranging from 1.02 to 2.03 mm. The F-Crimp terminal type guarantees secure connections, while its open barrel design enhances flexibility during installation. With a wide operating temperature range of -40 to 110°C, this product is perfect for HVAC systems and other industrial applications. RoHS compliant and part of the Quick Disconnects product line, the 60900-4 is a trusted solution for your terminal needs.
