5-160446-2
FF 250 REC 1.0-2.5MM2 TPPB
The 5-160446-2, a high-quality Fastin/Faston 250 series receptacle designed for efficient wire termination in HVAC applications. This straight orientation terminal features a durable phosphor bronze construction with tin plating, ensuring reliable performance in a wide operating temperature range from -40 to 110°C. Suitable for 13-17 AWG wires, this receptacle accommodates wire sizes ranging from 1.03 to 2.62 mm² with an open barrel F-crimp design for secure connections. With RoHS compliance and quick disconnect capability, the 5-160446-2 is a versatile and dependable solution for your crimp terminal needs.
| Product Category: | |
| Manufacturer: | TE Connectivity |
| Manufacturer Part Number: | TE Connectivity 5-160446-2 |
| Series: | FASTIN-FASTON 250 |
| Contact Material: | Phosphor Bronze |
| Contact Plating: | Tin |
| Overall Length: | 19.2 mm, .756 in |
| Material: | Phosphor Bronze |
| Compatible Tab Width: | .25 in, 6.35 mm |
| Compatible Tab Thickness: | .032 in, .81 mm |
| Terminal Type: | Receptacle |
| Orientation: | Straight |
| Operating Temperature Range: | -40 - 110 °C, -40 - 230 °F |
| Wire Size: | 13 - 17 AWG, 1.03 - 2.62 mm² |
| Crimp Type: | F-Crimp |
| Barrel Type: | Open |
| Accepts Wire Insulation Diameter: | .118 - .157 in, 3 - 4 mm |
| Product: | Quick Disconnects |
| Product Type: | Receptacle |
| SKU: | AMP5-160446-2 |
| Fully Insulated: | No |
| Connection Capacity: | Single |
| Receptacle Terminal Stock Thickness: | .41 mm / .016 in |
| Mating Retention Type: | Locking Lance |
| Wire Insulation Support: | With |
| Wire/Cable Type: | Regular Wire |
| Insertion Force: | Normal |
| Sealable: | No |
| Insulated: | No |
| Wire Stop: | No |
| Terminates To: | Wire & Cable |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
Product Change Notice
| Effective Date | Description of Change | Download |
|---|---|---|
| 03/15/2022 | P-22-022199 - Manufacturing location change. Following Part Numbers will be transferred from TE Lickdale to TE Collegno. | Download |
| 11/17/2017 | P-17-014917 - Manufacturing Location Change. TE business unit operations are simplifying our manufacturing footprint to provide a more continuous efficient supply of product. As a result, the parts noted in this document will be relocating products from TE Collegno, Italy to TE Lickdale, USA under the same certified quality management system. Note: Due to limited capacity and delivery urgency, we are waiving Agreement 91 wait-period for this transfer. | Download |
| 07/31/2014 | E-14-009319 - Document Clari?cation. Part and Drawing revision mismatch. | Download |
