40705

AMP40705
Heilind Number:AMP40705
Manufacturer:TE Connectivity
Manufacturer Number:40705
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

SPADE 164(4.17 MM) TERMINAL 18-14 AWG BR

More >>

Specifications

AttributeValue
Product Category:
Crimp Terminals, Housings, Splices, & Lugs Crimp Terminals, Housings, & Splices
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 40705
Contact Material:Brass
Overall Length:14.22 mm, .56 in
Stud Size:#8, M4
Orientation:Straight
Operating Temperature Range:-40 - 110 °C, -40 - 230 °F
Wire Size:14 - 18 AWG, 1624 - 4106 CMA, .8 - 2 mm²
Barrel Type:Open
Insulated:No
Product:Rings & Spades
Product Type:Spade Tongue
Terminal Angle:Straight
SKU:AMP40705

Detailed Description

Introducing the 40705, a high-quality SPADE 164 (4.17 MM) TERMINAL designed for reliable electrical connections in a variety of applications. Constructed from durable Brass, this terminal is built to last. With an overall length of 14.22 mm (.56 in) and a stud size of #8 or M4, it offers a universal fit. The straight orientation and operating temperature range of -40 to 110 °C (-40 to 230 °F) make it versatile for different environments. Suitable for wire sizes .8 - 2 mm² (14 - 18 AWG), it ensures a secure connection with 1624 - 4106 CMA. The open barrel type allows for easy installation, and with RoHS compliance, you can trust in its quality. Upgrade your electrical connections with the 40705 SPADE TERMINAL.
