322912

AMP322912
Heilind Number:AMP322912
Manufacturer:TE Connectivity
Manufacturer Number:322912
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

TERMINAL,SOLIS R 90DEG 2/0 3/8

More >>

Specifications

AttributeValue
Product Category:
Crimp Terminals, Housings, Splices, & Lugs Crimp Terminals, Housings, & Splices
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 322912
Connector Type:Ring Tongue
Stud Size:3/8
Operating Temperature Range:170 °C, 338 °F
Wire Size:0 AWG, 119500 - 150500 CMA, 60.6 - 76.3 mm²
Barrel Type:Closed
Insulated:No
Product:Rings & Spades
Terminal Angle:90°
SKU:AMP322912
Plating Material:Copper / Tin
Inspection Slot:No
Weight per Piece:28.331 g
Number of Holes:2
Stud Diameter:9.91 mm / .39 in
Tongue Thickness:.79 mm / .031 in
Barrel Inside Diameter:12.802 mm / .504 in
Government Qualified:No
Wire Insulation Support:Without
Heavy Duty:No
Wire/Cable Type:Regular Wire
Sealable:No
Shape Description:RING-046
Support Style:Non - Insulation Support

Detailed Description

Introducing the 322912, a high-performance 90-degree ring tongue terminal designed for robust electrical connections in demanding applications. This terminal, featuring a closed barrel construction, is engineered for secure and reliable wire termination, accommodating 2/0 gauge wires with a stud size of 3/8. With a wide operating temperature range of 170°C to 338°F, it ensures stable performance even in extreme conditions. RoHS compliant and non-insulated, this terminal is suitable for a variety of industrial settings. Trust in the quality and durability of the 322912 for your critical connectivity needs.
