MCSLPT4644B3TR
TACT MICRO JB 4.6X4.4X0.55 P3.5 200GF
The MCSLPT4644B3TR, a high-performance TACT MICRO JB switch designed for precision control in electronic devices. Featuring a compact 4.6x4.4x0.55mm footprint and a durable stainless steel contact material, this switch ensures reliable operation in demanding applications. The surface mount design and vertical mount angle make it easy to integrate into your circuit board layout. With a low amperage rating of 50mA and a rated voltage of 12VDC, this switch is ideal for power-sensitive systems. The SPST pole and throw configuration and Off-(On) switch operation provide accurate and responsive input control. RoHS compliant and with a 200g operating force, the MCSLPT4644B3TR offers both environmental sustainability and long-lasting performance. Upgrade your tactile and keyboard switches to the gold standard with the MCSLPT4644B3TR.
| Product Category: | |
| Manufacturer: | TE Connectivity |
| Manufacturer Part Number: | TE Connectivity MCSLPT4644B3TR |
| Amperage: | 50 mA |
| Mount Type: | Surface Mount |
| Contact Material: | Stainless Steel |
| Mount Angle: | Vertical |
| Illumination: | No |
| Actuator Type: | Flush, Top |
| Switch Operation: | Off - (On) |
| Operating Force: | 200 g, 7.055 oz |
| Actuator Material: | Polyimide |
| Pole and Throw Configuration: | SPST |
| Rated Voltage: | 12 VDC |
| SKU: | AMP2337234-3 |
| series: | Alcoswitch LPT |
| Case Color: | Black |
| Body Style: | Horizontal |
| Actuator Profile: | Flush |
| Case Material: | Thermoplastic |
| Tactile Feel: | Yes |
| Ganged: | No |
| Number of Actuators: | 1 |
| Tactile: | Yes |
| ESD Grounding Terminal: | Without |
| Switch Contact Plating Material: | Silver |
| Switch Height: | .5 mm / .022 in |
| Process Sealed: | No |
| Low Profile: | Yes |
| Product Type: | Switch |
| Leg Style: | J Style |
| Dust Proof: | No |
| Temperature Rating: | -20 - 70 °C |
| Supplier Product: | Tactile Switches |
| Part Alias: | 2337234-3 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
