2297813-3

Heilind Number:	AMP2297813-3
Manufacturer:	TE Connectivity
Manufacturer Number:	2297813-3
Datasheet:	Application Specification
ECAD Model:

Description:

BASE ASSY, 27 POSN ISO FUSE AND RELAY

More >>

Specifications

Attribute	Value
Product Category:	Automotive Connectors & Accessories Automotive Connectors
Manufacturer:	TE Connectivity
Manufacturer Part Number:	TE Connectivity 2297813-3
Maximum Operating Temperature:	125 °C, 257 °F
Pitch:	.307 in, .32 in, 7.8 mm, 8.13 mm
IP Rating:	IP67
Component Type:	Fuse Holder, Relay Holder
Contact Amperage:	20 A, 40 A
Number of Positions:	27
Relay Type:	ISO Mini
GPL:	J23
Operating Temperature Range:	-40 - 125 °C, -40 - 257 °F
Sealable:	Yes
GPL Description:	Industrial & Commercial Transportation
Product Code:	CF01
ECCN:	EAR99
Nominal Voltage Architecture:	12 V, 24 V
Fuse Type:	Mini ATM Fuse
Secondary Locking:	No
Number of Fuses Maximum:	6
Number of Relays Maximum:	3
Part Aliases:	2297813-3
SKU:	AMP2297813-3

Detailed Description

Introducing the 2297813-3, a high-performance BASE ASSY designed for automotive applications. This 27 POSN ISO FUSE AND RELAY holder features a durable construction with a maximum operating temperature of 125°C (257°F), making it ideal for harsh environments. With a pitch of .32 in (7.8 mm) for fuses and .307 in (8.13 mm) for relays, it offers versatile compatibility. Rated IP67 for dust and water resistance, this component ensures reliable performance. Suitable for Mini ATM fuses and ISO Mini relays, with a contact amperage of 20A for fuses and 40A for relays, it meets the demands of industrial and commercial transportation applications. RoHS compliant and sealable, the 2297813-3 guarantees both performance and environmental responsibility. Elevate your automotive connectivity with this essential fuse and relay holder.
