| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | TE Connectivity |
| Manufacturer Part Number: | TE Connectivity 2150730-2 |
| Product: | Applicators |
| Terminator Type: | 30 mm (1.12") Stroke Terminator, 40 mm (1.62") Stroke Terminator |
| Feed Type: | Pneumatic |
| SKU: | AMP2150730-2 |
2150730-2
| Heilind Number: | AMP2150730-2 |
| Manufacturer: | TE Connectivity |
| Manufacturer Number: | 2150730-2 |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the OCEAN 2.0_APPLICATOR-E-190F250F, a high-performance tool designed for precise and efficient termination tasks. This pneumatic applicator features a 30 mm (1.12") Stroke Terminator, as well as a 40 mm (1.62") Stroke Terminator, offering versatility for a wide range of applications. With its sleek design and durable construction, this applicator ensures reliable performance in any workspace. Rest assured, it is ROHS compliant, meeting strict environmental standards. Perfect for professionals in the connector and tool industry, the OCEAN 2.0_APPLICATOR-E-190F250F is a must-have for your toolkit. Elevate your termination processes with this top-of-the-line applicator.
For Use With
Product Change Notice
| Effective Date | Description of Change | Download | |||
|---|---|---|---|---|---|
| 03/20/2020 | E-20-002439 - Product Improvement. Ocean applicator 2150730 updated item 7 slug blade 1-1803366-5 is an improvement over current design resulting in optimization of cutting the slug out between the terminal. This change will be implemented on future applicator orders but is not required for the functionality of existing applicators in the field. | Download | |||
| 02/10/2020 | E-20-000495. Product Improvement. upgraded to OCEAN 2.0, to include: enhanced wire crimp height ram assembly, terminal drag plate function and air feed assembly. This change will be implemented on future applicator orders but is not required for the functionality of existing applicators in the field. Where listed on the applicator logs-sheet, all terminals have been qualified using the stated crimp specification. | Download | |||
