2-927768-1
JPT REC 2.8 Contact SRC Au
The JPT REC 2.8 Contact SRC Au, a high-performance automotive terminal designed for durability and reliability in a variety of applications. With a current rating of 30 A, this tin-plated contact ensures efficient power transmission. Its F-Crimp termination method accommodates wire sizes ranging from 1 to 2.5 mm², providing a secure and stable connection. Operating seamlessly in extreme temperatures from -40 to 150 °C (-40 to 302 °F), it is suitable for use in harsh environments. The terminal features a Locking Lance for added security and stability, making it ideal for automotive, truck, bus, and off-road applications. Rest assured, this product is RoHS compliant, meeting international standards for environmental responsibility. Upgrade your connectivity with the JPT REC 2.8 Contact SRC Au.
| Product Category: | |
| Manufacturer: | TE Connectivity |
| Manufacturer Part Number: | TE Connectivity 2-927768-1 |
| Amperage: | 30 A |
| Termination Method: | Crimp |
| Contact Plating: | Tin |
| Operating Temperature Range: | -40 - 150 °C, -40 - 302 °F |
| Wire Size: | 1 - 2.5 mm² |
| Crimp Type: | F-Crimp |
| Terminal Primary Locking Feature: | Locking Lance |
| Terminal / Splice Type: | Receptacle |
| Product: | Automotive, Truck, Bus, & Off-Road Terminals |
| SKU: | AMP2-927768-1 |
| series: | Junior Power Timer |
| Interface Plating: | Gold (Au) |
| Mating Tab Thickness: | .8 mm / .031 in |
| Mating Tab Width: | 2.8 mm / .11 in |
| Wire Insulation Diameter: | 2.1 - 3.1 mm / .083 - .122 in |
| Wire Size Search: | 14 AWG / 15 AWG / 16 AWG / 17 AWG / 1 mm² / 1.25 mm² / 1.3 mm² / 1.5 mm² / 2 mm² / 2.5 mm² |
| Agency/Standard: | DIN ISO 6722 part 3 |
| Terminal Transmits: | 25 - 40 A (Power) |
| Wire Type: | Copper |
| Sealable: | No |
| Receptacle Style: | 180° |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
