2-32994-1

AMP2-32994-1
Heilind Number:AMP2-32994-1
Manufacturer:TE Connectivity
Manufacturer Number:2-32994-1
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

TERMINAL,SOLIS R 12-10 8

More >>

Specifications

AttributeValue
Product Category:
Crimp Terminals, Housings, Splices, & Lugs Crimp Terminals, Housings, & Splices
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 2-32994-1
Connector Type:Ring Tongue
Stud Size:#8, M4
Orientation:Offset
Operating Temperature Range:170 °C, 338 °F
Wire Size:10 - 12 AWG, 3 - 6 mm², 5180 - 13100 CMA
Barrel Type:Closed
Insulated:No
Product:Rings & Spades
Terminal Angle:Straight
SKU:AMP2-32994-1
Plating Material:Copper / Tin
Inspection Slot:No
Weight per Piece:1.48 g
Number of Holes:1
Overall Length:19.43 mm / .765 in
Stud Diameter:4.34 mm / .171 in
Tongue Thickness:.79 mm / .031 in
Barrel Inside Diameter:3.277 mm / .129 in
Government Qualified:No
Wire Insulation Support:Without
Heavy Duty:No
Wire/Cable Type:Regular Wire
Sealable:No
Shape Description:RING-048
Support Style:Non - Insulation Support

Detailed Description

Introducing the 2-32994-1, a high-quality terminal designed for reliable electrical connections. This ring tongue connector, featuring a stud size of #8 or M4, is perfect for 10-12 AWG wires, with a wire size range of 3-6 mm². Its offset orientation and straight terminal angle make for easy and efficient installations. Operating flawlessly in temperatures up to 170°C (338°F), this terminal is a durable solution for your connectivity needs. With its closed barrel design and non-insulated construction, it ensures secure and efficient performance. Rest assured, this product is in stock and RoHS compliant, guaranteeing both quality and environmental responsibility. Trust in the 2-32994-1 for your critical connections.
