2-167301-2

Heilind Number:AMP2-167301-2
Manufacturer:TE Connectivity
Manufacturer Number:2-167301-2
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

MOD-4 REC.CONT.SCP

More >>

Specifications

AttributeValue
Product Category:
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 2-167301-2
Series:AMPMODU IV/V
Gender:Female
Termination Method:Crimp
Contact Material:Phosphor Bronze
Contact Type:Socket
Package Quantity:17500
GPL:277
Packaging:Reel
Contact Mating Area Plating:Tin
Contact Mating Area Plating Thickness:2 µm
GPL Description:Industrial
Connector and Contact Terminate To:Wire & Cable
Product Code:5207
Wire Size:20 - 24 AWG, .2 - .6 mm²
ECCN:EAR99
Applied_Pressure:Intermediate
Wire Insulation Support:With
Accepts Wire Insulation Diameter:.055 in, 1.4 mm
Compatible Wire / Cable Type:Discrete Wire
Wire Contact Termination Area Plating Material:Tin
Wire Contact Termination Area Plating Thickness:2 µm
Part Aliases:2-167301-2
SKU:AMP2-167301-2

Detailed Description

Introducing the AMPMODU IV/V MOD-4 REC.CONT.SCP, a high-performance female crimp socket connector designed for industrial applications. With a package quantity of 17,500, this contact features a durable phosphor bronze construction and tin plating for reliable conductivity. Termination is easy with compatibility for 20-24 AWG wire sizes, and the .2-.6 mm² wire insulation support ensures secure connections. RoHS compliant and featuring a 2 µm thick tin plating, this connector is ideal for wire and cable termination in a wide range of electronic devices.
