170376-2
EI-SRS COSI CONTACT
The EI-SRS COSI CONTACT, a high-performance male connector designed for signal applications. With a low amperage rating of 2 A, this pin contact is ideal for delicate electronic systems. Constructed from durable phosphor bronze, it ensures reliable conductivity. The cable mount (free-hanging) design allows for easy installation. With an operating temperature range of -20 to 105 °C (-4 to 221 °F) and excellent insulation resistance of 500 MΩ, it is suitable for a wide range of environments. Each package contains 15,000 pieces, making it perfect for large-scale projects. RoHS compliant and featuring pre-tin plating, this connector is both environmentally friendly and high-performing. Upgrade your wire-to-wire or wire-to-board connections with the EI-SRS COSI CONTACT.
| Product Category: | |
| Manufacturer: | TE Connectivity |
| Manufacturer Part Number: | TE Connectivity 170376-2 |
| Amperage: | 2 A |
| Gender: | Male |
| Mount Type: | Cable Mount (Free-Hanging) |
| Contact Material: | Phosphor Bronze |
| Contact Type: | Pin |
| Package Quantity: | 15000 |
| Insulation Resistance: | 500 MΩ |
| GPL: | 289 |
| Packaging: | Strip |
| Operating Temperature Range: | -20 - 105 °C, -4 - 221 °F |
| Circuit Application: | Signal |
| Contact Mating Area Plating: | Pre-Tin |
| Contact Mating Area Plating Thickness: | .38 µm |
| Sealable: | No |
| GPL Description: | Data and Devices |
| Connector and Contact Terminate To: | Wire & Cable |
| Product Code: | 1592 |
| Wire Size: | .12 - .5 mm², 26 - 20 AWG |
| Connector System: | Wire to Board, Wire to Wire |
| ECCN: | EAR99 |
| Dielectric Withstanding Voltage: | 750 V AC |
| Accepts Wire Insulation Diameter: | .043 - .075 in, 1.09 - 1.91 mm |
| Wire Contact Termination Area Plating Material: | Pre-Tin |
| Wire Contact Termination Area Plating Thickness: | .8 µm |
| Part Aliases: | 170376-2 |
| SKU: | AMP170376-2 |
Environmental Initiative Details
| Environmental Initiative: | RoHS |
|---|---|
| Compliant: | Unknown |
| Date of this Information: | Unknown |
| Notes: |
Product Change Notice
| Effective Date | Description of Change | Download |
|---|---|---|
| 04/01/2014 | P-13-009672 - Manufacturing location change. | Download |
