170014-5

AMP170014-5
Heilind Number:AMP170014-5
Manufacturer:TE Connectivity
Manufacturer Number:170014-5
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

FF 110 TAB 20-16AWG BR

More >>

Specifications

AttributeValue
Product Category:
Crimp Terminals, Housings, Splices, & Lugs Crimp Terminals, Housings, & Splices
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 170014-5
Series:FASTIN-FASTON 110
Contact Material:Brass
Contact Plating:Unplated
Overall Length:20.5 mm, .807 in
Material:Brass
Compatible Tab Width:.11 in, 2.8 mm
Compatible Tab Thickness:.02 in, .51 mm
Terminal Type:Tab
Orientation:Straight
Operating Temperature Range:-40 - 110 °C, -40 - 230 °F
Wire Size:16 - 20 AWG, .51 - 1.31 mm²
Crimp Type:F-Crimp
Barrel Type:Open
Accepts Wire Insulation Diameter:.079 - .118 in, 2.01 - 3 mm
Product:Quick Disconnects
Product Type:Tab
SKU:AMP170014-5

Detailed Description

Introducing the 170014-5, a high-quality Fastin/Faston 110 Tab Terminal designed for efficient wire connections in various applications. Constructed with durable brass material and featuring a 20-16 AWG wire size compatibility, this terminal ensures reliable conductivity. The unplated brass contact plating further enhances its longevity, while the F-Crimp design offers secure and easy installation. With an operating temperature range of -40 to 110°C, this terminal is suitable for use in demanding environments. Its straight orientation and 20.5mm overall length accommodate different connection needs, making it a versatile component for HVAC and other systems. RoHS compliant, the 170014-5 guarantees both performance and environmental responsibility. Upgrade your wire termination setup with this premium tab terminal.
