1658614-2

AMP1658614-2
Heilind Number:AMP1658614-2
Manufacturer:TE Connectivity
Manufacturer Number:1658614-2
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

25 POS HDF RCPT, AP, LEAD FREE

More >>

Specifications

AttributeValue
Product Category:
D-Sub & D-Ribbon Connectors & Accessories D-Sub Connectors
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1658614-2
Color:Black
Series:AMPLIMITE HDF
Amperage:1.25 A
Gender:Receptacle
Housing Material:Thermoplastic
Number of Contacts:25
Number of Rows:2
Mount Type:Cable Mount (Free-Hanging)
Termination Method:Insulation Displacement Crimp (IDC)
Contact Material:Phosphor Bronze
Contact Plating:Gold
Body Orientation:Straight
Pitch:.0545 in, 2.77 mm
Shell Size:3
Contact Size:20
Contact Type:Socket
Terminal Type:IDC
Mount Angle:Straight
Insert Material:Steel
Package Quantity:40
Cover Material:Thermoplastic
Cable Type:Ribbon Cable
Number of Positions:25
GPL:253
Profile:Low
Packaging:Tube
Operating Temperature Range:-55 - 105 °C, -67 - 221 °F
Circuit Application:Signal
Contact Mating Area Plating:Gold
Contact Mating Area Plating Thickness:30 µin
Shielded:Yes
Contact Underplating Material:Nickel
PCB Contact Termination Area Plating:Tin
Solid Wire Size:.1 - .13 mm², 28 - 26 AWG
PCB Retention Type:None
Sealable:No
Mating Connector Lock Type:Threaded Insert, 4-40 UNC
GPL Description:Data and Devices
Connector and Contact Terminate To:Wire & Cable
Product Code:4911
Preloaded:Yes
Wire Size:.08 - .15 mm², 28 - 26 AWG
Product Grade:Standard
Connector System:Cable-to-Cable
Connector Product Type:Connector
Mating Connector Lock:With
Ribbon Cable Centerline Spacing:.05 in, 1.27 mm
Cable Insulation Diameter:.032 - .038 in, .81 - .97 mm
Enclosure:Without
Threaded Insert Plating:Zinc
Grounding Indents:Without
Shell Type:All Plastic
Standards Met:UL 94V-0
Material Flammability Standard:UL 94V-0
Part Aliases:1658614-2
Strain Relief Part Number:747275-2
Optional Cable Stabilizer:747275-2
SKU:AMP1658614-2

Detailed Description

The 1658614-2 is a high-density black D-Sub connector from the AMPLIMITE HDF series, featuring UL 94V-0 standards for superior safety. With a current rating of 1.25 A, this receptacle connector is designed for reliable signal transmission. Housing made of thermoplastic and gold-plated phosphor bronze contacts ensure durability and excellent conductivity. With 25 contacts in a 2-row configuration, it offers ample connectivity. The cable mount design with insulation displacement crimp termination method allows for easy installation on ribbon cables. Its low-profile construction, operating temperature range of -55 to 105 °C, and ROHS compliance make it suitable for a wide range of applications. Each package contains 40 connectors, making it ideal for bulk installations in various electronic devices.
