1586845-1

AMP1586845-1
Heilind Number:AMP1586845-1
Manufacturer:TE Connectivity
Manufacturer Number:1586845-1
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

04P UMNL CAP HSG NATL, GW

More >>

Specifications

AttributeValue
Product Category:
Connectors Power Connectors
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1586845-1
Series:Universal MATE-N-LOK
Housing Material:Nylon
Number of Rows:1
Mount Type:Panel
Termination Method:Crimp
Pitch:.25 in, 6.35 mm
Voltage:600 V AC
Contact Type:Pin
Package Quantity:1
Panel Thickness:.76 - 2.29 mm
Number of Positions:4
Housing Color:Natural
GPL:236
Packaging:Package
Operating Temperature Range:-55 - 105 °C, -67 - 221 °F
Circuit Application:Power & Signal
Panel Mount:With
Panel Mount Type:Latches
Sealable:No
GPL Description:Appliances
Connector and Contact Terminate To:Wire & Cable
Product Code:1318
Contact Layout:Inline
Connector System:Wire to Wire
Connector Product Type:Housing
ECCN:EAR99
Contact Retention:Without
Glow Wire Rating:GWT 750°C (Without Flame)
VDE Tested:Yes
Connector and Housing Type:Receptacle
Multiple Contact Types:Without
Standards Met:UL
Material Flammability Standard:UL 94V-2
Part Aliases:1586845-1
SKU:AMP1586845-1

Detailed Description

The Universal MATE-N-LOK 1586845-1 is a versatile power and signal connector housing designed for reliable wire-to-panel termination in various appliances. With a UL-rated nylon construction and a natural housing color, this connector ensures safety and durability in both commercial and residential applications. Featuring a single row of 4 inline pin contacts with a 6.35mm pitch, it offers easy and secure crimp termination for wires and cables. With a high voltage rating of 600V AC and operating temperatures ranging from -55 to 105 °C (-67 to 221 °F), this connector is suitable for demanding environments. VDE tested and RoHS compliant, the 1586845-1 guarantees quality and environmental responsibility in its performance. Whether for HVAC systems or other industrial equipment, this connector is a reliable solution for power and signal connectivity.
