1551920-2

AMP1551920-2
Heilind Number:AMP1551920-2
Manufacturer:TE Connectivity
Manufacturer Number:1551920-2
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

zQSFP+ connector assembly

More >>

Specifications

AttributeValue
Product Category:
High Speed Connectors & Components High Speed Cage & Connector Assemblies
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1551920-2
Series:zQSFP+/QSFP28
Mount Type:Board Mount
Termination Method:Surface Mount
Contact Plating:Gold
Pitch:.032 in, 8 mm
Data Interface:zQSFP+
Contact Amperage:.5 A
Number of Positions:38
Data Rate:25 Gb/s
GPL:J25
Packaging:Reel, Tape
Operating Temperature Range:-40 - 185 °F, -40 - 85 °C
Circuit Application:Signal
Contact Mating Area Plating:Gold
Contact Mating Area Plating Thickness:30 µin, .76 µm
PCB Contact Termination Area Plating:Tin
PCB Thickness (Recommended):.057 in, 1.45 mm
Sealable:No
GPL Description:Data and Devices
Connector and Contact Terminate To:Printed Circuit Board
Product Code:L818
Connector System:Cable-to-Board
Connector Product Type:Connector
ECCN:EAR99
Standards Met:UL 94V-0
Material Flammability Standard:UL 94V-0
Part Aliases:1551920-2
SKU:AMP1551920-2

Detailed Description

Introducing the 1551920-2, a high-speed zQSFP+ connector assembly designed for reliable data transmission in demanding applications. This surface-mount connector features 38 gold-plated contacts, meeting UL 94V-0 standards for enhanced safety. With a low-profile .8mm pitch and a data rate of 25 Gb/s, it is ideal for high-density board mount configurations. Operating efficiently in a wide temperature range from -40 to 85°C, this connector is perfect for signal applications in various industries, including data centers and telecommunications. RoHS compliant and ECCN EAR99, the 1551920-2 guarantees quality and compliance for your connectivity needs.
