1217281-2

AMP1217281-2
Heilind Number:AMP1217281-2
Manufacturer:TE Connectivity
Manufacturer Number:1217281-2
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

FF 110 REC 24-20AWG TPBR

More >>

Specifications

AttributeValue
Product Category:
Crimp Terminals, Housings, Splices, & Lugs Crimp Terminals, Housings, & Splices
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1217281-2
Series:FASTIN-FASTON 110
Contact Material:Brass
Contact Plating:Pre-Tin
Overall Length:13.97 mm, .55 in
Material:Brass
Compatible Tab Width:.11 in, 2.8 mm
Compatible Tab Thickness:.032 in, .81 mm
Terminal Type:Receptacle
Orientation:Straight
Operating Temperature Range:-40 - 110 °C, -40 - 230 °F
Wire Size:20 - 24 AWG, .2 - .51 mm²
Crimp Type:F-Crimp
Barrel Type:Open
Accepts Wire Insulation Diameter:.05 - .08 in, 1.27 - 2.03 mm
Product:Quick Disconnects
Product Type:Receptacle
SKU:AMP1217281-2

Detailed Description

The 1217281-2 is a Fastin/Faston 110 series receptacle designed for efficient wire termination in HVAC applications. Constructed of pre-tin plated brass, this straight orientation terminal ensures reliable conductivity in temperatures ranging from -40 to 110°C. With a compact overall length of .55 inches, it accommodates 20-24 AWG wires with ease. Featuring an open barrel for F-Crimp installation, it accepts wire insulation diameters between .05 and .08 inches. This RoHS-compliant terminal, with SKU 1217281-2, guarantees high performance and durability in a variety of electrical connections.
