| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems RTS6BS14N12P03 |
| Gender: | Male |
| Housing Material: | Plastic |
| Number of Contacts: | 12 |
| Contact Material: | Copper Alloy |
| IP Rating: | IP67, IP69K |
| Shell Size: | 14 |
| Wire Size: | 24 to 14 AWG |
| Current Rating: | 13 A |
| Voltage Rating: | 500 VAC |
| Insert Arrangement: | 14-12 |
| Locking Mechanism: | Bayonet |
| Operating Temperature: | -40 to 125 °C |
| SKU: | AMERTS6BS14N12P03 |
RTS6BS14N12P03
| ICC Number: | AMERTS6BS14N12P03 |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Number: | RTS6BS14N12P03 |
| Datasheet: | Catalog |
| ECAD Model: |
Description:
ST PL , 12 POS, SZ 14,
Specifications
Frequently Bought Together
| Product | Part # | Description | Stock |
|---|---|---|---|
| Amphenol Sine Systems MP16M23F | Pin Contact, Machined, Gold Flash, Wire Range .75-1.5mm², 18-16 AWG | ![]() |
Product Change Notice
| Effective Date | Description of Change | Download | |||
|---|---|---|---|---|---|
| 11/14/2022 | C1733S-REV-A1 - Product Improvement. improved strength. After improving the strength of PL000470-14N/W/X/Y/Z, the fool-proofing capablity of the connectors will be better. | Download | |||
