| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems EP-8-14B |
| Gender: | Male |
| Series: | EP |
| IP Rating: | IP40 |
| Wire Size: | 14 AWG |
| Mount Type: | Chassis Mount |
| Housing Color: | Black |
| Mating Cycles: | 1000 cycle |
| Current Rating: | 15 A |
| Voltage Rating: | 100 V |
| Contact Plating: | Bright Tin |
| Contact Material: | Brass |
| Housing Material: | Die-Cast Zinc Alloy |
| Number of Contacts: | 8 |
| Termination Method: | Solder |
| Flammability Rating: | UL 94V-0 |
| Maximum Operating Temperature: | 75 °C |
| Minimum Operating Temperature: | -25 °C |
| SKU: | AMEEP-8-14B |
EP-8-14B
Specifications
Detailed Description
Introducing the EP-8-14B, a high-performance 8 Pole Male Metal Loudspeaker Chassis Mount connector designed for seamless audio connectivity. Featuring precision machined contacts and a durable die-cast zinc alloy housing with a sleek black finish, this connector ensures reliable signal transmission in any environment. With a solder termination method and brass contacts plated with bright tin, it guarantees secure and efficient connections. Rated for a maximum operating temperature of 75°C and a voltage of 100V, this connector is ideal for a wide range of audio applications. Its IP40 rating offers protection against dust and debris, while its UL 94V-0 flammability rating ensures safety. Perfect for audio, video, and broadcast systems, the EP-8-14B is a must-have for professional audio installations.
