| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems C146 C05 801 E8 |
| Color: | Black |
| Series: | Heavymate® M |
| Gender: | Female |
| Housing Material: | Nylon |
| Number of Contacts: | 5 |
| Termination Method: | Crimp |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP20 |
| Contact Size: | 2.5 mm |
| Mating Cycles: | 500 cycle |
| Wire Size: | 0.5 - 4 mm² |
| Current Rating: | 16 A |
| Voltage Rating: | 1000 V |
| SKU: | AMEC146 C05 801 E8 |
C146 C05 801 E8
Specifications
Detailed Description
Introducing the C146 C05 801 E8, a versatile 5-way female socket module from the Heavymate® M series. Constructed with durable black nylon housing and featuring 5 brass contacts with silver plating, this connector ensures reliable power transmission in industrial environments. With a crimp termination method and a contact size of 2.5mm, it accommodates wire sizes ranging from 0.5 to 4mm². Rated for a maximum operating temperature of 125°C and a voltage of 1000V, it is suitable for heavy-duty applications. This RoHS-compliant connector has an IP20 rating for added protection, and with a current rating of 16A and 500 mating cycles, it guarantees long-lasting performance. The C146 C05 801 E8 is the ideal solution for your power connectivity needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
