| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems AP-6-22 |
| Series: | AP |
| Gender: | Male |
| Housing Material: | Polyphenylene |
| Number of Contacts: | 6 |
| Mount Type: | Chassis Mount |
| Termination Method: | Solder |
| Contact Material: | Brass |
| Contact Plating: | Bright Tin |
| Maximum Operating Temperature: | 75 °C |
| Minimum Operating Temperature: | -25 °C |
| IP Rating: | IP40 |
| Housing Color: | Black |
| Mating Cycles: | 1000 cycle |
| Wire Size: | 12 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 20 A |
| Voltage Rating: | 200 V |
| SKU: | AMEAP-6-22 |
AP-6-22
Specifications
Detailed Description
The AP-6-22 is a high-performance 6 Pole Male Loudspeaker Chassis Mount connector designed for audio and broadcast applications. Featuring a durable thermoplastic shell with a sleek black finish, this connector is both rugged and stylish. Its rectangular flange allows for easy and secure panel mounting. With brass contacts and bright tin plating, it ensures reliable signal transmission. Rated for up to 20 A and 200 V, it can handle power-hungry audio systems with ease. The connector is solder terminated for a secure and permanent connection, suitable for high-vibration environments. Its IP40 rating provides protection against dust and debris. Designed for longevity, it offers 1000 mating cycles. Suitable for 12 AWG wire, it is ideal for high-power audio applications. With a UL 94V-0 flammability rating, it meets strict safety standards. The AP-6-22 is a versatile and reliable connector for professional audio and broadcast setups.
