D38999/26JE35SN

mil-dtl-38999-series-iii-tv
ICC Number:AAOD38999/26JE35SN
Manufacturer:Amphenol Aerospace
Manufacturer Number:D38999/26JE35SN
Datasheet:Catalog
ECAD Model:
3D Model

Description:

38999 SIII STR PLUG 55#22D

More >>

Specifications

AttributeValue
Product Category:
Circular Connectors & Accessories Circular Connectors
Manufacturer:Amphenol Aerospace
Manufacturer Part Number:Amphenol Aerospace D38999/26JE35SN
Number of Contacts:55
Contact Plating:Gold
Shell Size:17
Contact Type:Socket
Shell Material:Composite
Wire Size:28 to 22 AWG
Shell Type:Plug, Straight
Shell Finish:Olive Drab Cadmium
Current Rating:5 A
Voltage Rating:400 VAC
Insert Arrangement:17-35
Keying Position:N
Locking Mechanism:Threaded
Operating Temperature:-65 to 175 °C
MIL Type:MIL-DTL-38999
SKU:AAOD38999/26JE35SN

Detailed Description

The MIL-DTL-38999/26 Series III Circular Connector is a high-reliability, military-specification component designed for use in harsh environments. Featuring a straight plug configuration with 55 removable crimp contacts, this connector ensures secure and efficient electrical connections. With a gold contact plating for enhanced conductivity and a cadmium olive drab finish for environmental resistance, it offers reliable performance in a wide range of operating conditions. The composite shell construction with EMI/RFI shielding provides durability and signal integrity, making it ideal for aerospace, defense, and other demanding applications. Meeting stringent MIL-DTL-38999 standards, this connector guarantees long-lasting, high-performance connectivity in mission-critical systems.
